This range of UV systems from Certikin are simple to install and are supplied with stainless steel mounting brackets for either horizontal or vertical installation.
Bring water to life with Certikin UV-C
Certikin's range of UV systems consist of the CUV15 (15 Watt UV bulb), CUV25 (25 Watt UV bulb), CUV30 (30 Watt UV bulb), CUV55 (55 Watt UV bulb), CUV75 (75 Watt UV bulb), CUV110 (2 x 55 Watt UV bulbs) and CUV220 (4 x 55 Watt UV bulb).
Certikin UV systems ensure that your pool or spa will have amazing clarity, by killing the single cell algae that causes green water.
All systems have been designed using the latest design technology to ensure that the water will flow effectively within the unit, allowing the ultraviolet light to destroy the algae as it passes through.
The CUV has a low energy electronic ballast, fused with thermal overload protections. It can also withstand up to 4 Bar pressure.
The unit also features a fully UV stabilised, tough outer casing. This means the unit can withstand the recommended operating pressures.
Up to the 75w all units have 1.5" connections and 110w and 220w are 2".
All units are compatible with salt chlorinators.
Every model comes complete with a 2 year guarantee for total peace of mind.
The CUV is fully serviceable and both the lamp and control box can be replaced.
The lifespan of a Certikin UV bulb is approximately 9,000 hours (1 year) and the bulb should be replaced after this running time.
Model |
Size L x W X H mm |
15W |
525 x 88 x 167 |
25W |
525 x 88 x 167 |
30W |
995 x 88 x 167 |
55W |
995 x 88 x 167 |
75W |
1297 x 88 x 167 |
110W |
1040 x 170 x 285 |
220W |
1091 x 170 x 756 |
|
15W |
25W |
30W |
55W |
75W |
110W |
220W |
Max. Flow Rate m3 |
7.5 |
10 |
15 |
20 |
25 |
25 |
25 |
For swimming pools up to (m3) |
15 |
25 |
30 |
55 |
75 |
110 |
150 |
Number of bulbs |
1 x 15W |
1 x 25W |
1 x 15W |
1 x 55W |
1 x 75W |
2 x 55W |
4 x 55W |
Bulb life (hours) |
9,000 |
9,000 |
9,000 |
9,000 |
9,000 |
9,000 |
9,000 |
Inlet / Outlet
|
1.5" |
1.5" |
1.5" |
1.5" |
1.5" |
2" |
2" |
